HRM-M 1450 RPM N version 24mm

  • Technical Specifications
    Model Flow Pressure Power Weight RPM
    l/min gpm bar psi hp kw kg rpm
    HRM-M 01.08 1.0 0.26 80 1145 0.3 0.2 15.5 1450
    HRM-M 02.08 2.0 0.52 80 1145 0.5 0.4 15.5 1450
    HRM-M 04.08 4.0 1.06 80 1145 1.0 0.8 15.5 1450

    HPV-M 1450 RPM

  • Technical Specifications
    Model Flow Pressure Power Weight RPM
    l/min gpm bar psi hp kw kg rpm
    HPV-M 1,3.08 1.3 0.34 80 1145 0.8 0.6 13.8 1450

    HPV-M O 1450 RPM

  • Technical Specifications
    Model Flow Pressure Power Weight RPM
    l/min gpm bar psi hp kw kg rpm
    HPV-M O 1,3.10 1.3 0.34 100 1450 0.8 0.6 14.5 1450
    HPV-M O 3.10 3.0 0.80 100 1450 2.0 1.5 14.5 1450

    HPE-M 1450 RPM

  • Technical Specifications
    Model Flow Pressure Power Weight RPM
    l/min gpm bar psi hp kw kg rpm
    HPE-M 02.08 2.0 0.52 80 1145 0.5 0.35 22 1450
    HPE-M 04.08 4.0 1.06 80 1145 1.0 0.7 22 1450
    HPE-M 06.08 6.0 1.58 80 1145 1.0 0.7 22 1450
    HPE-M 08.08 8.0 2.11 80 1145 1.8 1.35 22 1450
    HPE-M 11.07 11 2.90 70 1015 2.2 1.65 22 1450
    HPE-M 13.06 13 3.43 60 870 2.2 1.65 22 1450

    HPE 1450 RPM

  • Technical Specifications
    Model Flow Pressure Power Weight RPM
    l/min gpm bar psi hp kw kg rpm
    HPE 10.12 - Brass head 10.0 2.64 120 1740 3.0 2.2 21.5 1450
    HPE 11.11 - Brass head 11.0 2.90 110 1600 3.0 2.2 21.5 1450
    HPE 13.10 - Brass head 13.0 3.43 100 1450 3.0 2.2 21.5 1450

    HRC 1450 RPM

  • Technical Specifications
    Model Flow Pressure Power Weight RPM
    l/min gpm bar psi hp kw kg rpm
    HRC 8.12 8.0 2.11 120 1740 2.5 1.8 19.2 1450
    HRC 8.14 8.0 2.11 140 2000 3.0 2.2 22.0 1450
    HRC 9.11 9.0 2.37 110 1600 2.5 1.8 19.2 1450
    HRC 9.14 9.0 2.37 140 2000 3.0 2.2 22.5 1450
    HRC 10.10 10 2.64 100 1450 2.5 1.8 19.2 1450
    HRC 11.11 11 2.9 110 1600 3.0 2.2 21.5 1450
    HRC 13.10 13 3.43 100 1450 3.0 2.2 21.5 1450

    HRC 1450 RPM

  • Technical Specifications
    Model Flow Pressure Power Weight RPM
    l/min gpm bar psi hp kw kg rpm
    HRC 10.13 10.0 2.64 130 1900 3.0 2.2 22.3 1450
    HRC 12.11 12.0 3.20 110 1600 3.0 2.2 22.3 1450
    HRC 11.15 11.0 2.90 150 2200 4.0 3.0 28.0 1450
    HRC 13.17 13.0 3.43 170 2500 5.5 4.0 30.0 1450
    HRC 14.16 14.0 3.70 160 2300 5.5 4.0 30.0 1450

    HRR 1450 RPM

  • Technical Specifications
    Model Flow Pressure Power Weight RPM
    l/min gpm bar psi hp kw kg rpm
    HRR 15.20 ET 15.0 3.96 200 2900 7.5 5.5 33.0 1450
    HRR 18.16 ET 18.0 4.75 160 2300 7.5 5.5 33.0 2800

    HRK 1450 RPM

  • Technical Specifications
    Model Flow Pressure Power Weight RPM
    l/min gpm bar psi hp kw kg rpm
    HRK 15.25 H 15.0 3.96 250 3600 10 7.5 56 1450
    HRK 21.20 H 21.0 5.55 200 2600 10 7.5 56 1450

    HXW 1450 RPM

  • Technical Specifications
    Model Flow Pressure Power Weight RPM
    l/min gpm bar psi hp kw kg rpm
    HXW 26.15 26.0 6.87 150 2200 10 7.5 63.0 1450
    HXW 30.10 30.0 7.92 100 1450 7.5 5.5 39.0 1450
    HXW 30.15 30.0 7.92 150 2200 10 7.5 63.0 1450
    HXW 30.20 30.0 7.92 200 2900 15 11 70.0 1450
    HXWL 42.10 42.0 11.09 100 1450 10 7.5 63.0 1450

    HSXW 1450 RPM

  • Technical Specifications

    Model Flow Pressure Power Weight RPM
    l/min gpm bar psi hp kw kg rpm
    HSXW 15.35 15.1 4.00 350 5100 15 11 75.0 1450
    HSXW 21.35 21.0 5.55 350 5100 20 15 115 1450

    HSHP 1450 RPM

  • Technical Specifications
    Model Flow Pressure Power Weight RPM
    l/min gpm bar psi hp kw kg rpm
    HSHP 15.50 15.0 3.96 500 7250 20 15.0 115 1450
    HSHP 20.50 20.0 5.30 500 7250 25 18.5 115 1450

    HRTX 1450 rpm

  • Technical Specifications
    Model Flow Pressure Power Weight RPM
    l/min gpm bar psi hp kw kg rpm
    HRTX 30.300 30 7.92 300 4350 25 18 135 1450
    HRTX 50.200 50 13.2 200 2900 25 18 135 1450
    HRTX 70.150 70 18.5 150 2200 30 22 135 1450
    HRTX 100.120 100 26.4 120 1750 30 22 135 1450

    HJRS 2800 RPM

  • Technical Specifications

    Model

    Flow

    Pressure

    Power

    Weight

    RPM


    l/min

    gpm

    bar

    psi

    hp

    KW

    kg

    rpm

    HJRS 01.09

    1

    0.26

    90

    1300

    0.3

    0.2

    19

    2800

    HJRS 02.09

    2

    0.52

    90

    1300

    0.5

    0.4

    19

    2800

    HJRS 04.09

    4

    1.06

    90

    1300

    1

    0.8

    19

    2800

    HJRS 06.09

    6

    1.6

    90

    1300

    1.4

    1.1

    19

    2800
